Quick Fuel Technology® - M-Series 650CFM Marine Carburetor

Quick Fuel Technology® M-650 - M-Series 650CFM Marine Carburetor

0 reviews|Item # mpn5250321888

Notes:

This model of carburetor has the square bore flange bolt pattern. It can replace Holley, Edelbrock, Carter AFB, and Autolite style carburetors with 5 3/16" x 5 5/8" bolt pattern. If you have a spreadbore style intake manifold, you will need an adapter to install this carburetor. Similar to the Mr. Gasket #1932
This is a Race Only product that is to be used solely for competition. It cannot be used on vehicles that are operated on public streets, roads or highways. Its use is limited to closed-course and open-course racing that is formally sanctioned by a recognized racing organization. Any other use, including recreational off-road use, could be in violation of local, state and federal laws. Shipping Restriction: CA, NY, ME

Authorized Dealer

$999.95

In Stock (4) - Ships in 24 to 48 hrs

Have a Question? Ask a Specialist

888-453-5144Live Chat

Specifications

Barrel Quantity	4
Barrels	4
Billet Color	Diecast-No Billet
Booster	Down Leg
Brand	Quick Fuel Technology
Carburetor Use	Marine
Category	Air and Fuel Delivery
CFM	650
Choke	Electric
Choke Type	Electric
Circuit	2
Condition	New
Cubic Feet Per Minute Rating	650
Emission Code	3
Finish	Black
Flange Type	Square/4150
Fuel	Gasoline
Fuel System	Carbureted
Gasket Or Seal Included	Yes
Grade Type	Performance
High Speed Air Bleed	31
Idle Air Bleed Size	70
Linkage Attached	Yes
Marine Engine Size	Universal
Marine Use	Yes
Material	Aluminum
Model	4150
Part Type	Carburetor
Primary Main Jet	71
Primary Power Valve	65
Primary Pump Nozzle Size	32
Product Type	Quick Fuel Marine Carburetor
Secondaries	Mechanical
Secondary Main Jet	78
Sub Category	Carburetion
Supercharged Application	No
Throttle Bore	1-11/16 inch
Warranty	Manufacturer's Limited 90 Day Warranty
UPC	849804000485
Part Number	M-650

Features

Exclusive Black Diamond coating for enhanced corrosion protection and appearance, coating provides a 6% reduction in fuel temperature
Electric choke - Fully adjustable, one wire hookup
J tubes to prevent spillage
PTFE-coated throttle shafts with PTFE bearing ribbons and stainless steel plates
Built-in sight glass windows for easy float adjustment
Changeable primary idle feed and power valve channel restrictions, plus changeable idle air and high speed bleeds
QuickLink™ secondary adjustment for fast and easy changing of opening rates
Available in eight different sizes from 350-1,050 cfm

Product Details

M-Series 650CFM Marine Carburetor by Quick Fuel Technology®. 650 CFM - 4150 - Mechanical Secondaries - Black - Gasoline. QFT brings its engineering expertise to the marine market. The M-Series feature billet-style metering blocks and throttle bodies for more precise performance and exceptional strength.
